Brass Rod D250mm Single Strand Copper Continuous Casting Machine
Brass Rod D250mm Single Strand Copper Continuous Casting Machine
Features Gallery Product Description Request A Quote
Basic Infomation
Place of Origin: CHINA
Brand Name: Jingjie
Certification: CE
Model Number: HCCM
High Light:

continuous caster machine


continuous casting machinery

Payment & Shipping Terms
Packaging Details: Packed in wooden case for outer packing
Delivery Time: 30 working days after received your payment
Payment Terms: T/T or L/C
Supply Ability: 10sets per month
Product Material: Brass
Product: Rod
Product Diameters: Φ250mm
Type: Horizontal
Length: 6m
Furnace Type: Melting And Holding Split Furnace
Melting Furnace Capacity: 2T
Holding Furnace Capacity: 2T
Product Description

Brass Rod D250mm Single Strand Horizontal Continuous Casting Machine Split Melting and Holding Furnace
Ⅰ. Specifications:

1. Material of casting specifications
* Brass Rod
1.1 Rod  billets (round-shaped)
* a. Diameter range -----Φ250mm
* b. Number of production lines -----Single Strand


 1. Main equipments of production line
  Melting furnace--Chute--Holding furnace-Mold--Micro-travel reversible casting machine--Synchronizing shearing machines-- Hydraulic unit--cooling unit--Electromechanical control unit etc.
  2.1 For casting of pure metal or special requirements, subsurface channel-type smelting-holding combination furnace or controllable channel-type smelting-holding combination furnace can be adopted;
  2.2 For producing round-shaped, tubular-shaped and special-shaped billets, cut-to-length synchronizing sawing machine can be adopted;
  2.3 For producing round-shaped, tubular-shaped and special-shaped billets, the material stock platform for receiving and storing billets can be adopted.

 Ⅲ. Equipment Components List of  Horizontal Continuous Casting Machine Production line for Bar Bar

No. Equipment Name and Spec. Unit Quantity Remarks
1 Melting furnace  set 1 Including melting groove, coil, waer jacket and iron core.
2 Chute set 1 One in-use and one standby
3 Holding furnace  set 1 Including melting groove, coil, water jacket, iron core, vertical temperature measurement device (specially-made), thermocouple (containing platinum and rhodium) and protection tube.
4 Molten steel storage ladle and chute set 1 For transferring material into the mold after sintering in holding furnace.
5 mold system (Ф250) set 2 Including graphite mold
6 Dragger (7.5KW) set 1
7 Synchronized auto-tracking sawing machine set 1
8 Material stock platform set 1 Chain drive, length of 6M
9 Header tank set 1
10 Traction carrier roller Set 1
11 Cooling water distributor set 1 Including cooling water for transformer, reactor, coil of electric furnace, water jacket, water-cooling cable, and mold (primary and secondary cooling).
12 Hydraulic system set 2

Including hydraulic station and cylinder
(The hydraulic components produced by YUCI YUKEN HYDRAULICS CO., LTD. are adopted)

13 Electric-control operation system of electric furnace set 1 Including the control cabinet for melting furnace and holding furnace (Siemens is chosen for main electrical elements).
14 Process control operation system set 1 For control of servo motor and process, synchronized auto-tracking sawing machine, and control of material stock platform.




Q1: What is your main brand for the electrical and mechanical parts?
A: China famous brand


Q2: could you please arrange the installation and commissioning ?
A: Yes , we could and the buyer pay the charge


Q3: could you arrange the production education?
A: Yes , we could and the buyer pay the charge


Q4: could you do the design for the whole plant
A: Yes , we can.
