Horizontal Slab Continuous Casting Machine For Copper Strip Oxygen Free
$80,000.00 - $200,000.00
Horizontal Slab Continuous Casting Machine For Copper Strip Oxygen Free
Features Gallery Product Description Request A Quote
Basic Infomation
Place of Origin: Wuxi China
Brand Name: Jingjie
Certification: CE/ISO
Model Number: 2 strands copper strip CCM
High Light:

ccm machinery


slab casting machine

Payment & Shipping Terms
Packaging Details: Wooden box, Standard export packing for
Delivery Time: 20-30 working days after received your payment
Payment Terms: T/T or L/C
Supply Ability: 50 sets per month
Product Name: Continuous Casting Machine
Product Type: Strips Slabs
Thickness Range * Width Range: 10-30mm
Type: Horizontal
Range Of Coil's Internal Diameter: Φ(500--800)mm
Max. Outer Diameter Of Coils: Φ1600 Mm
Dimension(L*W*H): Variable
Width: 150-650mm
Raw Materials: Brass ,bronze ,copper Etc.
Frequency: 50hz Or 60hz
Capacity: 1~30ton/day
After-sales Service: Engineers Available To Service Machinery Overseas
Product Description


Horizontal slab Continuous Casting Machine for Copper Strip for sale

Product Description:

Horizontal slab Continuous Casting Machine for Copper Strip for sale is mainly used for brass/bronze bar,brass/bronze tube making.The materials can be pure brass/bronze ,scrap brass/bronze and other brass/bronze materials.

Main composed parts :
1.Induction furnace
2. Traction machine
3. Automatic cutting machine
4. peeling machine(barking machine)
5. Electric control system
6.Water cooling system
7. Dust removal equipment.

Horizontal slab Continuous Casting Machine for Copper Strip for sale

Main technical parameters:

1. Casting speed: 1~30ton/day

2. Strip size: 150mm~650mm (width)


3. Furnace part:

Horizontal Slab Continuous Casting Machine For Copper Strip Oxygen Free 0Horizontal Slab Continuous Casting Machine For Copper Strip Oxygen Free 1Horizontal Slab Continuous Casting Machine For Copper Strip Oxygen Free 2

Horizontal slab Continuous Casting Machine for Copper Strip for sale




Mini. melting capacity Power Rated voltage Rated freq. Phase Operation temperature Power consumption (of melting) Cooling water pressure
Melting Holding
T/h T Kw Kw V HZ oC Kw.h/T Mpa
GYT-200 0.2 0.15 60 30


or as required

3 1250 300 0.2-0.4
GYT-300 0.3 0.2 90 45 280
GYT-500 0.5 0.3 120 55 260
GYT-750 0.75 0.5 180 70 260
GYT-1000 1 0.55 240 70 260
GYT-1500 1.5 0.6 360 95 240
GYT-2000 2 0.7 480 120 240
GYT-3000 3 0.85 720 160 230


Horizontal slab Continuous Casting Machine for Copper Strip for sale

The process diagram:

Horizontal Slab Continuous Casting Machine For Copper Strip Oxygen Free 3



Main equipments of production line
melting furnace, holding furnace, mold, micro-travel reversible casting machine, synchronizing shearing machines * 2, winding machines* 3, hydraulic unit, cooling unit, and electromechanical control unit etc.
* 1.1 For casting of pure metal or special requirements, subsurface channel-type smelting-holding combination furnace or controllable channel-type smelting-holding combination furnace can be adopted;

* 1.2 For producing round-shaped, tubular-shaped and special-shaped billets, cut-to-length synchronizing sawing machine can be adopted;

* 1.3 For producing round-shaped, tubular-shaped and special-shaped billets, the material stock platform for receiving and storing billets can be adopted.



1.1 Casting speed:
  Traction speed 0-64 mm/s (Stepless adjustable)
  Backstepping speed 0-64 mm/s (Stepless adjustable)
  Strip optimum line speed 90-120mm/min
1.2 Equipment power:

Combination furnace:






  Traction machine 7.5Kw
  Hydraulic shear stress 80T
1.3 Shear thickness 20mm(max)
1.4 Coiling machine parameters
  Coiling weight



  Inside Diameter of Coil



  Coil diameter 1600mm
1.5 Machine noise value Less than 85 dB
1.6 Height of machine operation line +1000mm
1.7 Machine drive direction Right drive
1.8 Production capacity
  2 Strands: 750-1200Kg/h width: 470mm thickness: 25mm
  Equipment assembly machine power 700Kw





1 Output 750-1200Kg/h
2 Temperature regulating range ≤1300℃
3 Temperature control precision of thermal insulation furnace ±5℃
4 Vertical and horizontal tolerance

Horizontal: + 0.10mm


5 Push and pull adjustment range

Push:0-64mm/s ±0.1mm(electrodeless)

Pull:0-64mm/s ±0.1mm(electrodeless)

6 Sickle curve 1.5mm/m
7 Dragger adjustment range

Drag:0-64mm/s ±0.1mm(electrodeless)

Backsteppingl:0-64mm/s ±0.1mm(electrodeless)

8 Drag maximum line speed 120mm/min
9 Coiling adjustment range

Inside Diameter of coil Φ500-Φ800mm

External diameter of coil Φ1600mm

10 Maximum coiling speed



11 Elastic adjustment range 0.95-0.75
12 Tower dgree of coiliing ≤40m
13 Unit power consumption 430kWh/t



No. Equipment Name and Spec. Unit Quantity
1 Machine parts
1.1 Melting and holding combined furnace set 1
1.2 Mould set 2
1.3 Dragger set 1
1.4 Hydraulic cutter set 1
1.5 Coiling machine set 2
2 Hydraulic system
2.1 Combined furnace titing hydraulic station set 1
2.2 Hydraulic cutter hydraulic station set 1
2.3 Dragger and coiling machine hydraulic station set 1
3 Electric control system
3.1 Power frequency electric furnace control system Set 2
3.2 Automatic control system set 1
4 Technical documentation with equipment set 2
4.1 Equipment installation diagram file 1
4.2 Equipment specification file 1
4.3 Principle diagram of electric control system file 1
4.4 Control cabinet layout file 1
4.5 Product specification for main electrical equipment file 1
4.6 Hydraulic system diagram file 1
4.7 PLC program file 1



    1. The main body of the equipment will have one year of free warranty, and special components shall be discussed separately;
    2. During the trial-production period (within 3 months after equipment commissioning is finished), our company will dispatch a professional technician for follow-up service;
Within the warranty period, if fault occurs due to quality problem, our company will dispatch personnel to the site to solve the problem within 72 hours after receiving the notice;
After the warranty period of the equipment is expired, our company will offer effective solutions within 24 hours after receiving the notice, and will dispatch personnel for maintenance work if the user fails to solve the problem, only charging the cost expenses.
For annual overhaul of equipment, our company will dispatch professional technician to join the users in formulating the turnaround plan, free of charge;
Within the warranty period, our company can dispatch professional technician to the site to check the operation condition of equipment and provide field service.
After the warranty period of equipment expires, one return visit can be made on invitation once per half a year.
    3. If our company has innovation and improvement points or constructive suggestions for similar equipments, we will inform the user in time.
