High Power Frequency Cooper Melting Furnace Core Electrical Induction
High Power Frequency Cooper Melting Furnace Core Electrical Induction
Features Gallery Product Description Request A Quote
Basic Infomation
Place of Origin: China
Brand Name: Jingjie
Certification: ISO/CE
Model Number: GVT
High Light:

brass melting furnace


bronze melting furnace

Payment & Shipping Terms
Packaging Details: Packed in wooden case for outer packing
Delivery Time: 30-45 working days after received your payment
Payment Terms: T/T or L/C
Supply Ability: 10-20 sets per month
Product Material: Red Copper,brass,bronze
Power: 1200kw
Rated Voltage: 600V
Phase Number: 3 Phase
Frequency: 60Hz
Maximum Melting Rate: 5t/h
Warranty: 12 Months
Product Description

High Power Frequency Core Electrical Induction Cooper Melting Furnace


Power frequency induction  furnace for semi continuous casting unit

1 Technical parameters
Rated power: 600kW * 2
Rated voltage: 600V
Phase number: 3 phase
Frequency: 60Hz
Power factor: 0.45 ~ 0.5 (compensation) 1 ~ 0.9 (compensation)
The three-phase power supply current unbalanced degree: less than 10%
Maximum melting rate: 5t/h
Max capacity: 12.0t
Minimum capacity: 1.5T (i.e., the melting body weight)
Heating temperature: 1200-1300
Heat preservation temperature: 1150 ~ 1200
There is class voltage regulation: 100V~600V ten
Cooling: water cooling
The cooling water temperature that is not higher than 40 DEG (coil, water jacket, water temperature measuring device)
Cooling water: 20 ~ 40t/h
Cooling water pressure: 0.2 ~ 0.4MPa
Groove type: W type rectangular jet melting groove

2 Scope of supply

1 1200kw Melting furnace   1set
2 Electric control 1200kw 1set
3 Furnace building material


Water jacket, coil, iron core, melting channel 1200kw 1set
5 Hydraulic tilting system With emergency stop switch, limit switch 1set
6 Water cooled cable


7 Auto-transformer   2set
8 Interphase reactor

400V, 430KVAR

9 Cooling water distribution and collection device                     1set

3 Main technical indicators of equipment
The main electrical components used in the domestic well-known brand products, furnace body using vertical structure, material using Q235, thickness of 16mm steel welded. Iron core is made of Wuhan Iron and steel 35Q135 high quality silicon steel sheet; melting ditch the T2 copper casting and; water-cooled sleeve adopts 3mm thick 1Cr18Ni9Ti welding; coil with 22 x 14.5 x 3mm thickness T2 hollow tube winding and; hydraulic system main fittings adopt Yuci production of products;
Two, 10T wire rod semi continuous casting machine
High Power Frequency Cooper Melting Furnace Core Electrical Induction 0High Power Frequency Cooper Melting Furnace Core Electrical Induction 1High Power Frequency Cooper Melting Furnace Core Electrical Induction 2
