Atmosphere Protection Hydrogen Annealing Furnace High Convection Flow Heating
1set
MOQ
negotiation
Price
Atmosphere Protection Hydrogen Annealing Furnace High Convection Flow Heating
Features Gallery Product Description Request A Quote
Features
Basic Infomation
Place of Origin: China
Brand Name: Jingjie
High Light:

bell type annealing furnace

,

electric annealing furnace

Payment & Shipping Terms
Packaging Details: Packed in wooden case for outer packing
Delivery Time: 30 working days after received your payment
Payment Terms: T/T or L/C
Supply Ability: 10sets per month
Specifications
Product Material: Copper Rod,barss Rod,steel Bar
Rated Temperature:: 900℃
Charging Capacity: ≥8T
Phase Number: 3 Phase
Frequency: 60Hz
Electric Heating Power: 220Kw
Product Description



Atmosphere Protection Hydrogen Annealing Furnace High Convection Flow Heating ​



1  Equipment name: Strong-convection bell-type annealing furnace



2  Technical parameters :

2.1  Effective charging size: Φ1600×3200mm

2.2  Charging capacity: ≥8T

2.3  Rated temperature: 900

2.4  Furnace temperature homogeneity: ±5 (mid-posterior section of heat preservation)

2.5  Temperature rise of furnace shell surface: ≤50

2.6  Electric heating power: 220Kw

2.7  Number of temperature control zones: 2 Zone (double-temperature and double-control)

2.8  Power of circulating fan: 37/11Kw Fan blade diameter: φ800

2.9  Cooling fan power: 1.5Kw x 2

2.10 Lifting height: ≥9m

2.11 Cooling process: Wind and water double-cooling

2.12 Equipment cooling water: 3m³/h

2.13 Process cooling water: 8m³/h

2.14 Atmosphere protection: Ammonia decomposition gas (Hydrogen 75% + Nitrogen 25%)





3  Equipment composition and price: (Single set)

No. Equipment name QTY.
1 Heating jacket(bell) 2pc
2 Furnace platform(with Circulating fan) 3 pc
3 Inner tank(retort) 3 pc
4 Cooling cover 1 pc
5 Electrical control system 2 pc
6 Accessories 1set
6.1 Vacuum pump (2X-70A), 1 for 2 sets 1 set
6.2 Lifting sling for inner cover 1 pc
6.3 Atmosphere valve stand 3 pc
6.4 Guide pin 1 set
6.5 Exhaust device 1 set
7 Ammonia decomposition device, capacity of 40m3 (Customer can provide by himself) 1 set





② The price quotation for 40m³ ammonia decomposition device with purification system

(Customer can also provide by himself), which can support 2 sets of furnaces mentioned-above.
